SGS Conveyor Weight Checker / Waterproof High Throughput Multi - Grade Weight Sorting Machine

SGS Conveyor Weight Checker / Waterproof High Throughput Multi - Grade Weight Sorting Machine

Products - Weight Sorting Machine
  • Highlight

    dynamic checkweigher

    ,

    checkweigher machine

  • Model
    VC-5G
  • Weight Range
    5-500g
  • Weight Grade
    6 Grade
  • Waterproof Rating
    IP67
  • Height From Ground To The Belt
    700 Mm + 50 Mm
  • Accuracy
    ± 1g
  • Place of Origin
    CHINA
  • Brand Name
    SHANAN
  • Certification
    CE, ISO
  • Model Number
    VC-5G
  • Minimum Order Quantity
    1 set
  • Price
    negotiation
  • Packaging Details
    Box
  • Delivery Time
    15work days
  • Payment Terms
    T/T
  • Supply Ability
    100 set/month

SGS Conveyor Weight Checker / Waterproof High Throughput Multi - Grade Weight Sorting Machine

  • SGS Conveyor Weight Checker / Waterproof High Throughput Multi - Grade Weight Sorting Machine
Get Price Contact Now



IP 67 Waterproof High Throughput Multi-grade Sorting Checkweigher



Features



  • Waterproof design with IP 65 protection Grade ( Optional)
  • Food and pharmaceutical hygiene standard
  • Standard machine structure and standard interface can suitable for wide range products
  • Easy panel operation with 10” inch touch screen
  • Up to 10 preset products memory, quick product changeover
  • Quick release drive unit for sample maintenance and easy cleaning
  • Speed adjustable by variable frequency motor
  • High speed and High precision, by high speed A/D Sampling Controller
  • Customized machine acceptable.
  • Zero tracking: Zero by manual or automatic, dynamic zero tracking available.
Model VC-M5
Weight range 5-500g
Max conveyor speed Approx 100-150 pcs / minute depends on different product
Weight grade Multi- grade can customized according to customer requirement
Max accuracy balance ±1g
Weigher sensor zone 250mm(L)*220mm(W) or customized
Weigher manner Strain resistance weigh
Rejection manner Air blast .push rod .flap drop
Operate manner Full touch screen control
Alarm method Buzzer alarm and light
Power supply AC110V/220V
Out dimension 2000mm(L)*675mm(W)81350mm±50mm
Package Strong ploy wooden case
