Multi Sorting Conveyor Weight Checker , High Accuracy Online Food Weighing Machine

Multi Sorting Conveyor Weight Checker , High Accuracy Online Food Weighing Machine

  • Highlight

    dynamic checkweigher

    ,

    checkweigher machine

  • Voltage
    110V-220V, 60 HZ
  • Conveyor Belt Running Speed
    10-110 Meter Adjustable
  • Detecting Range
    5g ~ 5000g
  • Gross Weight
    250 Kg
  • Accuracy
    ± 0.1 G
  • Sorting Grade
    3 Grades
  • Language
    English, Chinese, Spanish , Italian And Other Language ( All Of Language Can Be Customized)
  • Place of Origin
    CHINA
  • Brand Name
    SHANAN
  • Certification
    CE, ISO
  • Model Number
    VC-M3
  • Minimum Order Quantity
    1 set
  • Price
    negotiation
  • Packaging Details
    Box
  • Delivery Time
    15work days
  • Payment Terms
    T/T
  • Supply Ability
    100 set/month

Multi Sorting Conveyor Weight Checker , High Accuracy Online Food Weighing Machine





Multi-sorting Checkweigher , Food Weighing machine , Online Check weigher

Widely used in seafood, poultry, aquatic products, frozen products etc.



Checkweigher VC-M Series

  • 1. Replacing labor sorting, saving cost, improving efficiency and optimizing the production process
  • 2. Accurate rejector systems with multi-weight zone
  • 3. Various fast rejector systems, to satisfy rejecting unqualified products with different speed
  • 4. 3 standard weight sorting zones , 11 weight sorting zones is available.








Specifications

Model VC-M3 VC-M4 VC-M5 VC-M6
Detecting Range 10~600g 20~2000g 20~2000g 20~5000g
Scale Interval 0.05g 0.1g 0.1g 0.2g
Accuracy(??) 0.4g 0.8g 0.8g 1.5g
Detecting Speed(Max speed) 200pcs/min 160pcs/min 130pcs/min 110pcs/min
Maximum Belt Speed 60m/min 60m/min 60m/min 60m/min
The Weighed Product Size Width 150mm 220mm 220mm 290mm
Length 200mm 250mm 350mm 400mm
Weigher Platform Size Width 160mm 230mm 230mm 300mm
Length 280mm 350mm 450mm 500mm
Operation Screen 7-inch Touch LCD Screen
Product Storage Quantity 100 kinds
Maximum Weight Range 12 Levels
Sorter Sorting (Optional)
Power Supply AC220V (Optional)
Degree of Protection IP30/IP54/IP66
Body Material Stainless Steel (SUS304)



Note

  • 1. The technical parameter above namely is the result of accuracy by checking only the test sample on the belt.The accuracy would be affected according to the detecting speed and product weight.
  • 2. The detecting speed above will be affected according to the product size to be checked.
  • 3. Requirements for different sizes by customers can be fulfilled.



Note

  1. 1. The technical parameter above namely is the result of sensitivity by detecting only the test sample on the belt. The sensitivity would be affected according to the products being detected, working condition and also the different positions the metal mixed with.
  2. 2. Requirements for different sizes by customers can be fulfilled.



Multi Sorting Conveyor Weight Checker , High Accuracy Online Food Weighing Machine 0

FAQ


1. Are you manufacturer or trader?
We are manufacturer, we have own factory in Dong Guan, we have independent department for purchasing, producing, processing, testing, packing, storing , and transportation, believe our team is best team in china.
2. Do you sell the accessories for Products ?
Yes. We have Match the parts for our testing equipment. If our machines damages by fire, water flood, earthquakes, unsteady of power and other natural disasters, we are willing supply match parts with lowest price for you.
3.How about the packing for product? Is it easy damaged during transportation?
For light structure products like Gold detector. Hand held metal detector and so on we takes of strong carton box .
For heavy structure products like conveyor belt needle detector. Food metal detector X ray machine .Our packing is Standard Export ploy Wooden Case.
Every prepackage have a plastic bags cover .
4.How about your after-sales policy?
Customer first is our always principle . All of our products normal warranty is 12months. We give necessary back or video guidance for daily problems. If massive products occur big quality problems. Our technical and engineer support overseas service .
5.Do you accept customer Logo and customized ?
we accept kinds of customized and logo of all of our products for customers

Our Service

24 Hour after- sales service
12 months warranty
Professional technical guidance
Lifelong technical support
