Advantages for using metal separator:
1. Protect production device;
2. Enhance production efficiency;
3. Improve the availability of raw material;
4. Enhance product’s quality;
5. Reduce the expense of maintenance and shuts-down;
Technical Parameters:
| Model |
Dimension(mm) |
Sensitivity (Fe) |
Sensitivity (SUS) |
Air compression |
Max.throughput(L/H) |
Defectives eliminated time |
Installation height(mm) |
| VMD-25 |
25 |
0.2mm |
0.4mm |
3~5Bar |
300 |
0.3~5s |
330 |
| VMD-35 |
35 |
0.3mm |
0.5mm |
3~5Bar |
400 |
0.3~5s |
330 |
| VMD-50 |
50 |
0.5mm |
1.0mm |
3~5Bar |
2000 |
0.3~5s |
330 |
| VMD-70 |
70 |
0.8mm |
1.2mm |
3~5Bar |
5000 |
0.3~5s |
330 |
| VMD-100 |
100 |
1.0mm |
1.5mm |
3~5Bar |
12000 |
0.3~5s |
473 |
| VMD-120 |
120 |
1.2mm |
2.0mm |
3~5Bar |
16000 |
0.3~5s |
473 |
| VMD-150 |
150 |
1.5mm |
2.5mm |
3~5Bar |
25000 |
0.3~5s |
600 |
| VMD-200 |
200 |
2.0mm |
3.0mm |
3~5Bar |
44000 |
0.3~5s |
922 |
| VMD-250 |
250 |
2.5mm |
3.5mm |
3~5Bar |
69000 |
0.3~5s |
948 |
Features :
- Compact design
- Compliant with GMP requirements
- Compliant with CE - EMC regulations
- Excellent stability and accuracy
- Easy to use with auto-setting function
- High sensitivity - balanced coil technology
- Dust and water proof, easy to be cleaned Modular design enables the quick parts replacement and easy maintenance
- Adopted the latest technology of phase tracking, auto-balance and multi-frequency support
Note:
1. The detection aperture size can be made up to 250mm.
2. The technical parameter above namely is the result of sensitivity by detecting only the test sample on
the belt. The sensitivity would be affected according to the products being detected, working condition
and also the different positions the metal mixed with.
3. Detecting capacity per hour is related with product weight, the value of the table is according to the
density of water (1000kg /m3).
4. We much appreciate if you attach the filled product info questionnaire with your enquiry.
