Pharmaceutical industrial for medicine tablet processing metal detector price
Company introduce:
Vfinder is a manufacturing company specialized in the design, engineering and production of Metal Detectors .check weigher .needle detector and Electromagnetic Inspection Devices.we offering solution for food industry ,Pharmaceutical industry , Textile garment industry ,Rubber industry .Tory industry where the factory need help to control their quality for find broken needles and metals .
Under our solution and machine support our valued customer can accreditation with the FDA ,ISF ,HACCP even FCCA request and requirement .
Meanwhile we strongly support the all the world public security career.with our support by our product of walk through metal detector and x ray baggage scanner . So many public can be safety , so many dangerous products can been keep away from public people .
FEATURES
Color Touch Screen LCD operation system, easy to operate
Digital processing technology, high Sensitive to all kinds of metals
Advanced auto learn and manual learn to ensure wet/dry product detection well
32 different products parameters preset, easy to recall and edit
Multi-Languages operation system including Chinese, English, Spainish language
Stainless steel 304 and 316 Structure meet HACCP requirements
All contact parts with material can be fast disassembled for daily clean
Quick auto reject system
APPLICATION
Used to detect metals in capsules or tablets in pharmaceutical factories
Used to quality control in pharmaceutical industry
SPECIFICATION
Model No.: MD-25-3
Aperture Size: 139mm(W)x40mm(H)
Sensitivity: Fe 0.4mm; Non-Fe 0.6mm;SUS316 0.8mm
Hopper Size: 120mm(W)x25mm(H)
Hopper Height: 800mm-1300mm(Adjustable)
Alarm Method: Sound Alarm with Automatic rejector
Working Environment: Working Temperature: - 5°C- 40 °C
Power Source: AC220V±7%; 50Hz;1P
Dimension: 730mm(L)x730mm(W)x1150mm(H)
Packing Size: 830mm(L)x830mm(W)x1350mm(H)
Weight: N.W.: 100kg; G.W.: 120KG
Technical Parameters:
| Model | VDM-8T | VDM-8T | VDM-8T | VDM-8T | |
| Cutting caliber | Φ25mm | Φ35mm | Φ50mm | Φ75mm | Φ100mm |
| accuracy | Φ0.2mm | Φ0.3mm | Φ0.5mm | Φ0.7mm | Φ1.0mm |
| Amount | 250KG/HR | 300-400 KG/HR | 700-800 KG/HR | 1000-1500 KG/HR | 2000-2500 KG/HR |
| voltage | 220V/50~60Hz | 220V/50~60Hz | 220V/50~60Hz | 220V/50~60Hz | 220V/50~60Hz |
| Temp | -10~+80 | -10~+80 | -10~+80 | -10~+80 | -10~+80 |
| Nesting time | 0.3-5S | 0.3-5S | 0.3-5S | 0.3-5S | 0.3-5S |
| Compressed air | 3~5Bar | 3~5Bar | 3~5Bar | 3~5Bar | 3~5Bar |
| Dimension | 318X230X326(mm) | 318X230X326(mm) | 318X230X326(mm) | 378X270X350(mm) |
390X280X385(mm) |
Our products are sold all over the world, you can rest assured.
