Meat, Poultry & Fish
The Meat, Poultry and Fish sector covers a wide variety of different animal based protein products, which starts with raw, primary-processed meat (i.e. beef, pork, lamb), poultry (chicken or turkey), fish and seafood. It extends to secondary processing and beyond, which includes marinated, fermented or cooked meats, bacon, sausages and hot dogs, speciality meats, meat puddings, pâté and terrines, and includes ready to cook raw meat and fish products, whether they are fresh or frozen.
Quicker to Clean
All parts are IP69, designed to be accessible for quick and easy cleaning with no drying time needed, production can recommence immediately to free up cleaning resources for other tasks and increasing the overall production capacity.
Better Food Safety
The equipment is more hygienic to avoid bacterial contamination of the food, preventing a factory food safety risk, protecting the brand, satisfying COP and Food Safety Standards, and overall providing bacterial prevention reassurance.
Improved Reliability
Designed to full IP69 rating, the specification is less susceptible to water ingress damage, protecting it against corrosion, keeping the machine operating at all times, and so reducing breakdown costs and the associated down-time costs. SA- is the ideal solution in high-care factories to ensure reliability, longevity and reduced overall ROI.
Application
Wildly applicable in most of industry like food processing, chemical, pharmaceuticals, cosmetics, toy, etc.
Parameter
| No. | Part | SA-4009 | SA-4012 | SA-4015 | SA-4017 | SA-4020 |
| 1 | Size of Effective Width(mm) | 400 | 400 | 400 | 400 | 400 |
| 2 | Size of Effective Height(mm) | 90 | 120 | 150 | 170 | 200 |
| 3 | Width of PU Belt (mm) | 380 | 380 | 380 | 380 | 380 |
| 4 |
Body length (mm) (Without rejector) |
1500 | 1500 | 1500 | 1500 | 1500 |
| 5 | Belt height, above ground (mm) | 800±50 | 800±50 | 800±50 | 800±50 | 800±50 |
| 6 | Belt speed(m/min.) | 32 | 32 | 32 | 32 | 32 |
|
7 |
Sensitivity (Air test of center) (mm) |
FE:0.8 NFE:1.0 SUS304:1.2 |
FE:1.0 NFE:1.2 SUS304:1.5 |
FE:1.0 NFE:1.5 SUS304:1.8 |
FE:1.2 NFE:1.5 SUS304:2.0 |
FE:1.2 NFE:1.5 SUS304:2.0 |
| 8 | Maximum Weights to drive (KG) | 25 | 25 | 25 | 25 | 25 |
| 9 | Sorting/Rejecting device |
Belt Stop with audible and visual alarm (Down belt,Flipper,Pusher optional) |
||||
| 10 | Power | AC 220V±10% 50Hz(60Hz) | ||||
Note: The sensitivity above is only based on the Test Sample. The actual sensitivity would be affected by the product being inspected and working environment.
