Application
Wildly applicable in most of industry like food processing, chemical, pharmaceuticals, cosmetics, toy, etc.
Parameter
| No. | Part | SA-4009 | SA-4012 | SA-4015 | SA-4017 | SA-4020 |
| 1 | Size of Effective Width(mm) | 400 | 400 | 400 | 400 | 400 |
| 2 | Size of Effective Height(mm) | 90 | 120 | 150 | 170 | 200 |
| 3 | Width of PU Belt (mm) | 380 | 380 | 380 | 380 | 380 |
| 4 |
Body length (mm) (Without rejector) |
1500 | 1500 | 1500 | 1500 | 1500 |
| 5 | Belt height, above ground (mm) | 800±50 | 800±50 | 800±50 | 800±50 | 800±50 |
| 6 | Belt speed(m/min.) | 32 | 32 | 32 | 32 | 32 |
|
7 |
Sensitivity (Air test of center) (mm) |
FE:0.8 NFE:1.0 SUS304:1.2 |
FE:1.0 NFE:1.2 SUS304:1.5 |
FE:1.0 NFE:1.5 SUS304:1.8 |
FE:1.2 NFE:1.5 SUS304:2.0 |
FE:1.2 NFE:1.5 SUS304:2.0 |
| 8 | Maximum Weights to drive (KG) | 25 | 25 | 25 | 25 | 25 |
| 9 | Sorting/Rejecting device |
Belt Stop with audible and visual alarm (Down belt,Flipper,Pusher optional) |
||||
| 10 | Power | AC 220V±10% 50Hz(60Hz) | ||||
Note: The sensitivity above is only based on the Test Sample. The actual sensitivity would be affected by the product being inspected and working environment.
Features
※ Detector is made by hard filling technology with better stability.
※ An intelligent learning function, automatically set parameters with simple operation.
※ Multiple filtering algorithm, X - R orthogonal decomposition algorithm, stronger anti-interference.
※ Phase intelligent tracking technology, better stability.
※ Anti-interference photoelectric isolation drive, remote installation operation panel.
※ Based on adaptable DDS and DSP technology, they can improve detection sensitivity and stability.
※ Store 100 kinds of product parameters by ferromagnetic random-access memory.
※ Frame and roller made by 304 stainless steel, strong and durable.
※ Can detect all kinds of metal including Iron, Stainless Steel, Copper, Aluminum.
