Model
|
SA-990
|
|
Machine length (mm)
|
1330~2000 (can customize)
|
|
Detection tunnel width (mm)
|
200~1200 (can customize)
|
|
Detection tunnel height (mm)
|
50~1000 (can customize)
|
Standard detection sensitivity
|
FE(Φmm)
|
≥0.5
|
|
NON-FE(Φmm)
|
≥0.8
|
|
SUS304(Φmm)
|
≥1.0
|
|
Protection level
|
IP67
|
|
Number of memory products
|
200+ kinds
|
|
Display mode
|
Touch Screen
|
|
Operation mode
|
Touch button input
|
|
Alarm mode
|
Alarm stop, buzzer alarm or rejector device optional
|
|
Machine material
|
Stainless steel 304, fit for HACCP, GMP, FDA, CAS and other standards
|
|
Conveyor belt material
|
Food grade PVC or PU belt
|
|
Machine weight
|
About 280KG
|
|
Motor
|
90~370W
|
|
Transfer speed
|
10-28m/min (optional and adjustable)
|
|
Power supply
|
AC220V±10%, 50-60HZ (Customize AC110V or AC380V)
|
|
Belt height above the ground (mm)
|
700+100 (can customized)
|
|
Maximum load (single piece)
|
10~50KG (can customized)
|
|
Using environment
|
Temperature: -15℃~40℃, relative humidity: 30~85RP
|
