Technical standards |
Technical parameters |
By size |
800(W)×650(H)mm |
Conveyor speed |
Hour detection 600ps / h toy shoes products 0.22m/s |
Load |
150 kg |
Resolution |
∮0.0787 mm |
Conveyor height from the ground |
700mm |
Penetration |
≥8mm |
Monitor |
BenQ 19in LCD monitor |
Storage |
500G hard drive to save any image in real time, can store more than 100,000
and can make any image processing, and continuous work to save. |
Noise |
≤55dB(A) |
Operating system |
windowsXP |
Single check dose |
One-time inspection of the X-ray light source irradiation amount ≤ 1.22uGy |
Leaking radiation dose rate |
Away from any device outer surface of 5cm, the ray irradiation leak rate should
be ≤ 0.12uGy / h |
Dimensions |
(L) 1750mm (W)730mm(H)1200mm |
NW / GW |
280 kg / 350 kg |
