Model
|
SAXR-4025
|
|
X-ray source
|
VJX IXS100 150W/210W 80kV
|
|
Detect maximum width(mm)
|
250 (can customize)
|
|
Detect maximum height (mm)
|
400 (can customize)
|
Best empty machine detection accuracy
|
FE(Φmm)
|
≥0.4
|
|
Glass ball(Φmm)
|
≥1.0
|
|
Ceramic ball(Φmm)
|
≥1.0
|
|
Overall equipment size
|
1650x530x1895 mm
|
|
detector
|
DT X-Scan C 0.4 mm
|
|
conveyor belt
|
10-60m/min speed adjustable
|
|
Display
|
17-inch full-color touch screen
|
|
Maximum load-bearing capacity of conveyor
|
5Kg
|
|
operating system
|
Windows 11
|
|
working environment
|
Temperature: 0‒40°C Humidity: Relatively moderate 30~90%, no condensation
|
|
X-ray leak
|
< 1 microsievert/hour
|
|
Exclude organizations (optional)
|
Swing bar/Push plate removal/Flip plate/Blow
|
|
Protection method
|
Removable protective curtain/shield
|
|
Equipment fixation and mobility
|
The feet can be raised and lowered. If the rejection device is a stand-alone machine, it should be the same as the main machine.
|
|
power supply
|
AC 220V
|
|
Protection level
|
IP65
|
|
Body material
|
SUS304
|
