What is a check weigher?
A metal detector check weigher incorporates two parts, metal detector and check weighter. Checkweighers are known also as belt weighters in-motion scales, conveyor scales, dynamic scales, and in-line scales. A checkweigher make sure that every product leaving the production line is the right weight. They are key to ensuring that manufacturers provide quality products to improve customer satisfaction.
If you need to ensure products are within a certain weight range and free of metal contaminants, our checkweighers and metal detectors are sure to provide an ideal solution. Our range includes a variety of metal detectors for sale, in addition to quality check weighter that provide accurate, high-precision measurements. If you’re looking to buy a metal dertctor for food processing and inspection.
Our check weigher standard features:
Self-diagnosis function, when Rom/Ram, A/D light electric tube.
Belt disassembling without tools, which is easier to clean
Reject system : arm, air blast or pneumatic pusher for selecting;
Easy to replace: can store a variety of formulations, convenient for the replacement of product specifications;
Parameter details :
| Product model | SACW-120A | Transfer speed | 20~60m/min |
| Power supply | AC220V士10%50HZ(60HZ) | Maximum speed | 180 pcs/min |
| Rated power | 0.15KW | Weighing conveyorbelt size | 250mm(L)*20mm(W) |
| sinngle weighing range | 1.5-200g | Elimination method | Blow-out |
| Presetproduct number | 士0.05g~士0.1g | Control System | High speed A/Dsampling controller |
| Minimum scale | 0.01g | Preset product number | 2000pcs |
| Inspection item size | Length:30~150mm Width:30~90mm Height:10-100mm |
| Machine Size | 900mm(L)*500mm(W)*1250mm(H) |
| Operation direction | Facing the machine,left to right |
| Externalair supply | 中8mm |
| Air pressureinterface | Temperature:0C~40C,Humidity:30%~95% |
| Working environment |
Stainless steel 304 polished |
| Body material | Chinese, English,Turkish, Spanish, etc. |
| Operationscreen display | Windshield (colorless and transparent), calibration weight |
| Other standardequipment | 650mm~750mm(can be customized) |
| Height of beltsurface from ground | High speed A/D sampling controller |
| Protection level | Protection level conforms to IP-65 international standard |
| Remarks | According to the different dimensions of the tested product andthe working environment in which the equipment is running, the accuracyof the speedometer is slightly different |
Scope of application :
teat test
Our products are sold all over the world, you can rest assured.
