What is a check weigher?
A metal detector check weigher incorporates two parts, metal detector and check weighter. Checkweighers are known also as belt weighters in-motion scales, conveyor scales, dynamic scales, and in-line scales. A checkweigher make sure that every product leaving the production line is the right weight. They are key to ensuring that manufacturers provide quality products to improve customer satisfaction.
If you need to ensure products are within a certain weight range and free of metal contaminants, our checkweighers and metal detectors are sure to provide an ideal solution. Our range includes a variety of metal detectors for sale, in addition to quality check weighter that provide accurate, high-precision measurements. If you’re looking to buy a metal dertctor for food processing and inspection.
Our check weigher standard features:
Self-diagnosis function, when Rom/Ram, A/D light electric tube.
Belt disassembling without tools, which is easier to clean
Reject system : arm, air blast or pneumatic pusher for selecting;
Easy to replace: can store a variety of formulations, convenient for the replacement of product specifications;
Parameter details :
| Product model | SACW-500Automatic check weigher | Rated power | 0.4KW |
| Weighing scale | <40Kg | Highest sorting accuracy | 土5g~士30g |
| Minimum scale | 1g | Conveyor speed | 20~35m/min |
| The fastest speed | 30pcs/min | Eliminate speed | Push rod |
| Presetproduct number | 2000 | External steam source | 0.6-1Mpa |
| Air interface | Φ8mm | Single weighing range | <40Kg |
| Test item size | ≤650mm(L)*490mm(W) |
| Weigh the size ofthe conveyor belt | 1075mm(L)*500mm(W) |
| Transport direction | Face the machine, left in and right out |
| Work environment | Temperature:0C~40°C Humidity: 30%~95% |
| Other standard equipment |
Windshield (colorless and transparent),standard weight |
| The height of beltom the ground(mm) | 650mm~750mm(Can be customized) |
| Alarm way | Detect metal foreign body automatically stop operation, and sound the alarm |
| Mechanicaldimensions | 1880mm(L)*935mm(W)*1060mm(H) |
| Machine material | 304 stainless steel polished finish |
| Control system | High speed A/D sampling controller |
| Power supply | Aone-wayAC200V-240V(110V/380V Can be customized) |
| Operationscreen display | Chinese, English (Customized in Turkish, Spanish, etc.) |
| Protection level | Comply with IP-65 international standard |
| Note | According to the dimensions of the tested products and the working environmentof the equipment, the accuracy of the detection accuracy and thespeedometer is slightly different |
Scope of application :
Our products are sold all over the world, you can rest assured.
