120W Conveyor Belt Metal Detector For Food Packaging 12 Month Warranty

120W Conveyor Belt Metal Detector For Food Packaging 12 Month Warranty

  • Highlight

    non ferrous metal detector

    ,

    food safety detector

  • Product Name
    Metal Detector
  • Certificate
    CE, ISO, SGS
  • Tolerance
    Fe: 0.8 Mm, Non-fe: 1.0 Mm, SUS: 1.2 Mm
  • Tunnel Window
    50 X 20 Cm
  • Height From Ground To The Belt
    800 Mm + 100 Mm
  • Warranty
    12 Month
  • Place of Origin
    CHINA
  • Brand Name
    SHANAN
  • Certification
    CE, ISO
  • Model Number
    VDF-5020
  • Minimum Order Quantity
    1 set
  • Price
    negotiation
  • Packaging Details
    Box
  • Delivery Time
    15work days
  • Payment Terms
    T/T
  • Supply Ability
    100 set/month

120W Conveyor Belt Metal Detector For Food Packaging 12 Month Warranty

Overview
New technology industrial conveyor belt metal detector for food packaging
Quick Details
Type: industrial metal detectors
Brand Name: V FINDER
Product name: Food Industrial Full Digital Metal Detector
Electrical source 110V/60hz 220V/50hz
Power 120W
Raw Material: SUS304 and 201
Transfer ability: 5KG
Place of Origin Dongguan, China
Model Number VDF-5020
Detection window 500 mm (Width) x 200 mm (Height)
Screen: Digital
Rejection sytem pusher/air jet/drop down
Belt width(MM): 200


Introduction


Advanced technique of electrical & mechanism designs is adopted for EJH series digital intelligent auto-conveying metal detector which have reasonable structure, beautiful appearance, highly detection sensitivity and stable behaviors. It is characterized by high detecting sensitivity and stable & reliable performance.
Comparing with traditional simulation detector , the function is more complete , the capability is more stable and dependable. It accord with the demand of certification-HACCP, QS, ISO9001, FDA.



Main Features

1) Made of 304 stainless steel, durable and nice appearance, conveyor and pallet assembly used in the U.S. "FDA" standards of white non-toxic materials.

2) Digital machine, memory function for registering various products(Max: over 12 items)

3) adopt the combine technology of double signal and detection circuit, LCD display, with Chinese and English menu, easy operation.

4)Adopt Germany professional detection technology with balanced principle, more reliable, better performance.Dual-channel and frequency detecting ferrous, non-ferrous and stainless steel

5) DSP and MCU combination of the detection signal for data sampling and data processing, improve the detection results.

6)a new circuit design, high sensitivity, mature phase adjustment technology, can adjust the products automatically, inhibit the products effect effectively.

7)Able to detect iron, stainless steel, copper, aluminum and other non-ferrous metals and other materials.

8)With the learning function of automatic identification, overcome the effect of products materials efficiently, strong anti-interference and shock proof.

9)Support 24 hours non-stop working.

10) fairly good waterproof ability, apply to high temperature, low temperature, damp, dry, dust, dew and other poor work environment.



Table of Sensitivity



  25*8cm 30*10cm 40*15cm 50*20cm 60*30cm
FE ≥0.5mm ≥0.8mm ≥0.8mm ≥1.0mm ≥1.5mm
SUS ≥1.2mm ≥1.5mm ≥2.0mm ≥2.5mm ≥3.0mm

Remark: the above data is empty machine sensitivity. The real sensitivity will be lower on condition of different products being tested.

Way of alarming: sound and light alarm, stop running automatically.



Performance


Detection style: digital intelligent with LCD display
Language : English,
Motor power: 200w/400w
The main material: SUS 304
Speed of transmission: 18-40 meter/minute
height of inspection window(cm):10
width of inspection window(cm):40

Highest Sensitivity: Ferrous 0.5mm diameter ball
